SteerCATH
Steerable Catheters

SteerCATH^Ⓡ Steerable Catheters are used percutaneously to guide a .038 inch (.97 mm) diameter wire guide to a specific kidney area for delivery of contrast media and access, advancement, or replacement of wire guides. The catheter has an internal stainless steel braided catheter material.

Explanation

Accurately Mentor Your Next Treatment
Quickly Access Indicated Anatomy with the Steerable Catheter

Steercath Steerable Catheters is used percutaneously to
guide a .038 inch(.97 mm) diameter wire guide to a specific kidney area for delivery of contrast media and access, advancement or replacement of wire guides. The catheter has an internal stainless steel braided catheter meterial.

Knowledge

The SteerCath Catheter is designed with a steerable/articulating distal tip. Articulation is achieved via a steering dial at the proximal handle which allows the operator to manipulate the tip up to 180 degrees in opposing directions. The steering dial and steerable tip are connected via two operating wires. The wires are located on both lateral walls of the microcatheter shaft with a connection point on the distal microcatheter. Tension is applied to either one of the wires by turning the steering dial for manipulation of the tip direction. Once the direction of the steerable tip is determined, the steering dial lock may be used for maintaining the intended direction. The microcatheter lumen can accommodate steerable guide wires. A hydrophilic coating is applied to the distal 80 cm catheter surface. The marker bands facilitate fluoroscopic visualization. The proximal end of the microcatheter incorporates a standard Luer adapter for the attachment of accessories.

QR for User Guide

https://invamedoncology.com/img/qr/167-qr-user-guide-1694413122.png

Detailed specifications

We develop and manufacture standard or customized configurations of steerable catheter delivery systems to meet your device needs. From concept to manufacturing, we offer full-service steerable catheter production.

ADVANTAGES

Eliminates the need to change directives to reach the desired position
Conformability
Curve retention
Radiopaque type
Hydrophobic coated
Up to 180 degrees Control
Precise deflection using the self-locking rotating knob allows you to maintain control of the full procedure
Adjustable Tip Deflection
Make certain kink resistance
Torque control

Our steerable configurations are fully customizable.

Standard handles in 1-way and 2-way designs.

Customized handles for multidirectional devices.

Customized bend radius and deflection angle, including one-way, two-way, and multiplanar deflection.

Precision steering and torque response are required for structural heart and electrophysiology catheters.

Custom configured to achieve specified curve and desired stiffness of the tip and shaft segments

Accurately Mentor Your Next Treatment

Quickly Access Indicated Anatomy with the Steerable Catheter

SteerCATH^ⓇSteerable Catheters are used percutaneously to

guide a .038 inch(.97 mm) diameter wire guide to a specific kidney area for delivery of contrast media and access, advancement, or replacement of wire guides. The catheter has an internal stainless steel braided catheter material.
