Viper
Pharmacomechanical Thrombolysis System
ViperⓇ Thrombolysis Catheter is designed for controlled infusion of tPA along with mechanical vibrations.
| Design | OTW Design | |
| Sheath Lenght | 90cm, 135cm | |
| Catheter Profile | 5F | |
| Infusion Port | 20 cm of diatal tip | |
| Radiopacity | Ring marker from distal tip to 3mm | |
| Guidewire Compatibility | 0,035" | |
| Catheter Inner Layer | PTFE | |
| Structure of the Catheter | PE/PEBAX |
A Thrombectomy catheter, which is advanced directly and advanced over the wire, is used to open the lumen and dissolve the thrombus in acute occlusions in the presence of acute massive pulmonary embolism. The system has a specially designed tip to dissolve the thrombus. Pharmacomechanical thrombolysis is performed by delivering the necessary fluids to the vein with a special tip and applying thrombolytic drugs to the pulmonary embolism area by using low-power ultrasonic waves.
Detailed specifications
Over the guide wire system and 90 and 135 catheter lenght allows safe acces to the clotted target vessel including pulmonary artery in PE cases.
The lumen is used to facilitate passage of a guide wire which is allow 0,035" (0,36 mm) in diameter.
ViperⓇ Pharmacomechanical Thrombolysis Catheter, also can be use Vein / Pulmonary Artery.
During the application of tPa , pharmacomechanical thrombolytic
therapy is performed with the help of these micropores in the contents of the catheters.
Totally includes 30 micropores(10 micron) both side at the distal tip of 20 cm.
- Peripheral Veins
- Pulmory Artery
- IVC
SCIENTIFIC ARTICLE
Innovative Design
- No securement Hooks
- Minimized risk of fracture
- No risk Migration
- Allows easy penetration and smooth transition.
- Provides lesion access: Exceptional trackability, even in the most challenging anatomy
- Shapes and sizes to meet your peripheral challenge
| Design | OTW Design | |
| Sheath Lenght | 90cm, 135cm | |
| Catheter Profile | 5F | |
| Infusion Port | 20 cm of diatal tip | |
| Radiopacity | Ring marker from distal tip to 3mm | |
| Guidewire Compatibility | 0,035" | |
| Catheter Inner Layer | PTFE | |
| Structure of the Catheter | PE/PEBAX |
| Order Number | Device outer diameter | Working Length | RO | Infusion Zone | Guidewire Compatibility |
| VS1055 | 5.0 Fr | 90 cm | 3 mm from distal | 20 cm | 0.035" |
| VS1056 | 5.0 Fr | 90 cm | 3 mm from distal | 20 cm | 0.035" |
